Siddhivinayak Engineering manufactures BOPP Labeling Machine with state-of-the-art technology for the labeling process, ensuring fast, accurate and consistent labeling every time. Our wide range of Labeling Machine includes bopp wrap around labels, bopp labeling machines, automatic bopp labeling machine, automatic bopp labelling machine for square bottle, bopp labelling machine for square bottle. We offering our customer to choice of different machines such as bottle labelling machine bopp, bopp bottle labeling machine, auto bopp labeling machine, BOPP Labeling Machine Manufacturer from Ahmedabad, Biaxial Oriented Polypropylene Labeling Machine, High speed BOPP hot melt glue labeling machine, Hot Melt Glue BOPP Labeling Machine Manufacturers India, OPP/BOPP Labeling Machine.
2/4
Automatic BOPP Labeling Machine
This High Performance & advance technology Automatic Shrink Sleeve Label Applicator Machine is design to insert sleeve with desired position on various size and shape of bottles. Shrink Sleeve Labeling Machine is suitable for variety of industries with an opportunity to reduce labour and increase manufacturing rates. This Automatic Sleeve Label Machine is very compact and very simple mechanical gearing system hence very less maintenance.This Shrink Sleeve Label Applicator Machine has integrating functions of delivering & Space creating between the containers, Accurate cutting of label sleeving and proper positioning the sleeve on bottle. Automatic shrink sleeve labeling machine is constructed on a sturdy welded steel frame completely enclosed in stainless steel doors and Polycarbonate sheet doors.
This versatile Automatic Shrink Sleeve Label Applicator Machine model requires only 2 parts as a change parts (Mandrel & feed Screw Only) for change over from one size to another. No Tool require for changeover which will make easy and quick changeover. Hence very quick change over. The Automatic Shrink Sleeve Label Applicator unit consisting of sleeve roll loader-carrier assembly, conveyor bottle separating assembly, Mandrel /Sleeve Fromer, Bottle orientation/ positioning mechanism, High Speed Sleeve Cutter, Optical scanner, controlling assembly and Brush assembly etc.
This Automatic Sleeve Label Applicator Machine model operates with great simplicity, high efficiency and minimal maintenance with production capacity up to 500BPM.
Technical Data
| Model | SVOPP 300 |
|---|---|
| Direction of Movement | Left to Right |
| Output/Min* | Up to 300 Labels / Min. |
| Power Supply | Three Phase 415V, 50Hz AC Supply (Can Customized as Client Need) |
| MOC | Stainless Steel 304, Anodized Aluminum, |
| Machine Dimension | L 2500 mm * W 1150 mm * H 1800 mm |
| Label Roll Core | 76 mm |
| Label Roll Diameter | 300 mm |
| Container Diameter | Ø30~90 mm (Special Size Can be Customized) |
| Container Height | 100~300 mm (Special Size Can be Customized) |
|---|---|
| Label Material | BOPP |
| Stop Tolerance | +/ -1 mm |
| Label Size | 30 mm to 100 mm |
| Air Supply | 5 CFM @ 6 Bar |
| Machine Weight(kg) | 1000 |
Salient Features
No Bottle No Label
Stainless Steel Construction Including Main Machine Frame
Color Touch Screen HMI
Precisely Design Vacuum Drum From High Rigid Material To Reduce Friction And Static
Temperatures Of The Glue Store Can Be Easily Adjusted By The Operator Screen
Failures Of The Machine Can Be Seen On The Screen Along With The Codes
The Least Glue Consumption And Maintenance Cost
Modular Design Of Change Parts- Easy And Quick Change Over
Partial Machine Guarding
Vibration-Free Slat Chain Conveyor With Variable Speed Drive
Very Smooth and precise Operation
On-Line Speed Can Be Varied At Single Point
Advanced PLC Controlled System
Built-In Product Counter
AC Drive For Speed Control
Height Adjustable Legs
Easy To Adjust Label Cutting Knife
Optional Features
Label Roll Empty Alarm
When the label rolls empty, Machine stops with the alarm
In Feed / Out Feed Jamming Sensor
When In Feed / Out Feed bottle jamm – Machine stop with alarm
Missing Label
Machine stop with alarm or online pneumatic operated product rejection system
Safety Cabinet
To get more hygienic environment and ensure safety & quality use safety cabinet
Tower Light
Tower light Indicates the status of the process
Batch Code Printer
Online batch code / barcode / 2D matrix code printing on label
Inspection & Rejection System
Online vision Inspection and rejection system (21 CFR PART 11 compliance).
Main Electrical Configuration
| Part Name | Make | Description |
|---|---|---|
| PLC Control system | Panasonic | 32 I/O PLC |
| Touch-screen | Pansonic | 7 " Tocuh Screen HMI |
| Cutter Motor | Panasonic | Servo Motor |
| Cutter Home Positiong Sensot | Panasonic | Micro Sensor |
| Photoelectric sensor (Check object) | Wanglore / Leuze | Diffuse type Sensor |
| Label sensor (Check opaque label） | Leuze | Fork Type Label Scanner |
| Label Unwinder Sensor | Wanglore / Leuze | Diffuse type Sensor |
| Part Name | Make | Description |
|---|---|---|
| Conveyor Motor | Born Vario | Induction Gear Motor |
| Speed Controller Drive | Danfoss / Schneider | Variable Frequency Drive |
| Bottle Space Creator Motor | Oriental Motor | Compact AC Gear Motor |
| Label roll Unwinder Motor | Born Vario | Induction Gear Motor |
Application
PET
HDPE
Glass
Food
FMCG
Mineral Water
Oil
Beverages
Soft Drinks
Cold Drinks
Mineral Water
Edible Oil
Juice
Range of Automatic Shrink Sleeve Label Applicator Machine
We as a trusted manufacturer and exporter of BOPP Labeling Machine as they are often called, we supply all types of bopp applicator, bopp labeler applicator, bopp label machine, square bottle bopp labelling machine, BOPP Labeling Machine, bopp label printing, OPP labeling Machine. We are a prominent supplier of high functioning labelling machinery. With an understanding of specific industry requirements, we offer a large range of bopp labelling machine, bottle bopp labelling machine, bopp labeling machine cost, Hot Melt Labeling Machine, automatic bopp labeler machine manufacturer.
We are an ISO 9001:2015 registered firm that has supplied BOPP Labeling Machine in over 30 countries around the world. Our complete range of bopp labeler machine, bopp auto labeling machine, automatic bottle labelling machine bopp, fully automatic bopp labeling machine, bopp label applicator. Produce a wide range of comprehensive solutions with special designs as per customer requirement of bopp labeling machine manufacturer, bopp labelling machine manufacturer, hot melt bopp labeling machine, Hot Melt Glue Labeling Machine, semi automatic bopp labeling machine, Hot-Melt BOPP Labeling Machine, Automatic Bopp Hot Melt Labeling Machine.
BOPP Sticker Labeling Machine is a highly modern and efficient labeling equipment for product labeling in various industries such as food and beverage, cosmetic, pharmaceutical, chemical, FMCG, Pesticides and other related industries. Siddhivinayak Engineering offers a wide range of bopp label printing machine, bopp labeler, bopp label machine manufacturer, stainless steel bopp labelling machine, bopp label applicator machine. We offers our customers a wide range of products, including ss bopp labelling machine, bopp labeling machine price, bopp labelling and filling machine, Paper Round Glue BOPP Labeling Machine, Water Bottle Bopp Labeling Machine, HDPE Bottle Bopp Labeling Machine, BOPP (HOT MELT TYPE) Labeling Machine.
